The Importance of Crane lubrication Management

Crane lubrication is very important for the crane parts. Same as other machinery, crane’s operation must reply on the adequate lubrication.
If lubricating oil failure, the crane will begin to wear down. So the correct lubrication is very important to the crane. Different parts’ lubrication should be checked each 2~3 month according to the different location. As for the cranes working in harsh conditions, lubrication cycle should be reduced accordingly.

1.Crane lubrication position

2.The gearbox, open gear, wheel bearing, rail, motor bearing, the brake etc.

3.Here we discuss the crane lubrication position in detail:

Crane lubrication should follow the requirement of maintenance manual, different brands of lubrication oil should not be mixed.

• Gearbox: normally oil pool should be used for lubrication, summer with N100 load gear oil or 30 gear oil, winter with N78 load gear oil or 20 gear oil.
• Hydraulic brake actuator: summer with 25 transformer oil, winter with No. 10 aviation oil or instrument oil.
• The lubrication of the wire rope is made of synthetic graphite calcium base grease or other wire rope grease, and the grease is coated on the steel wire rope. Pay attention to make sure the penetration of oil entering into the wire rope.
• Various parts of the bearing, gear coupling and open gear should be lubricated with lithium based grease, 2 in summer, winter with No. 1.
• For joints and bolts with a slight relative movement, lubricated with calcium or lithium based grease or 45 oil.

Crane lubrication matters need attention

• Gearbox lubricating oil increase the amount of oil or oil needle into the upper and lower limits of calibration, not higher than the upper limit, if excessive oil spill will occur.
• Lubricating oil should always be kept clean. If you use grease, clean up the previously used grease.
• Regular cleaning of oil pipeline, to keep the oil path smoothly.
• Different models, different brands of oil shall not be mixed use.
• On above point 2 lubricating oil and grease for the recommended model specifications, customers can use the experience and the relevant information on the selection of lubricants more suitable for different occasions of lubricating oil and grease. The selection of the time to pay attention to consider the condition, load, temperature, dirt etc. If there is water at the points, sodium based grease should not be used.
